Mobile biometric terminal
SD917V2
SD917V2 5 inch Android Biometric terminal device：
Key Features:
√ Android 12.0 system
√ 5 inch color LCD with touch panel
√ FAP10/FAP20/FAP30 Biometric fingerprint sensor/reader
√ Support RFID card reader
Key Features:
√ Android 12.0 system
√ 5 inch color LCD with touch panel
√ FAP10/FAP20/FAP30 Biometric fingerprint sensor/reader
√ Support RFID card reader
Quantity
Product Specification | |
os | Android 12 |
CPU | Octa-core MT6272, 2.0GHz |
Memory | 2+32GB and 4+64 GB as option |
| bluetooth | 5.0 |
Biometric | Optical FAP20 /FAP30 Biometric fingerprint sensor/reader,Suprema BioSlim2 or CMB-E3 or Maxis fingerprint scanner FBI/FIPS 201 image quality specification, PIV-071006, Advanced CMOS sensor; Resolution 500DPI. 256*360pixels, 8- bit grey level, LDF- five finger detection feature and MOSIP SBI2.0 compliance,ISO19794-2/4, ANSI381 and WSQ supported, AES encryption according to NIST MINEXT III, support dry,wet&rough finger detection; |
IRIS(optional) | Support |
Facial Recognition(Optional) | Support |
Camera | Front:5.0M,Rear 13mp or 8.0M pixel front+13M pixel Rear camera for option |
GPS | GPS, Beidou as option |
Contactless | Support RFID card reader, 13.56 MHZ;ISO14443 Type A/B, Mifare®, ISO18092 compliant |
Barcode scanner (Optional) | Honeywell and Newland Barcode laser scanner |
Communicate | Wifi, 802.11 a/b/g/n 2G: GSM/GPRS/EDGE; 3G:WCDMA HSPA UMTS 859/900/1700/1900/2100Mhz 4G: FDD-LTE B1 B3 B7 B8 B28, TDD-LTE B38 B39 B40 B41B |
IP rating | IP54 standard and withstand 1.2m falling testing with silicon cover to reach IP64 |
DC charging | 3.5MM DC Jack slot |
Card slots | Dual SIM, Dual PSAM slot, support TF card |
Peripheral Ports | Dual USB ports:Type A USB 2.0 OTG and Type C |
Battery | 3.7V, 5000mAh; Li-ion Input:100-240V AC; Output:5V DC, 2A |
Accessories | 1xSF365; 1X OTG USB cable; 1X adapter;1X handbelt strip; 1X Protective silicon cover;1*DC charger |
Dimension | 235(L)×140(W)×19(H) |
| Product Application |
Law enforcement officers can use biometric PDA terminal to record case details, collect evidence, take photos, and record videos during outdoor law enforcement. And the fingerprint recognition function of the biometric fingerprint PDA can collect fingerprint information for identity information collection and verification. These data can be directly stored in the mobile biometric terminal and can be uploaded to the server or shared with other law enforcement personnel at any time for subsequent case analysis and reporting
